HomeSTIHLSTIHL Kombi SystemKombi Engine STIHL KMA 130 R Skin Only
Previous product
STIHL AP 300 S Battery With Bluetooth $369.00
Back to products
Next product
MSA 160 36 volt C-B Skin Only $499.00

STIHL KMA 130 R Skin Only

$699.00

Powerful 36V battery KombiEngine with high torque and low weight. Three power levels for energy-efficient and low-noise work in all applications, harness. Weight: 3.2 kg. To run the KMA 130 R with an AP battery the following accessories need to be used; battery belt with AP holster plus connecting cable, or AP carrying backpack system.

Shipping Note

  • Free shipping on orders above $750
  • We only deliver across the Sydney area
Add to Wishlist
Compare
Categories: Kombi Engine, STIHL Kombi System
Share
Facebook Twitter Pinterest linkedin Telegram
  • Description
Description

Powerful 36V battery KombiEngine with high torque and low weight. Three power levels for energy-efficient and low-noise work in all applications, harness. Weight: 3.2 kg. To run the KMA 130 R with an AP battery the following accessories need to be used; battery belt with AP holster plus connecting cable, or AP carrying backpack system.

Technical Data

Technical data Value
Weight kg 3.2
Length mm 1) 913
Rated Voltage V 36
Rated voltage V 36
Weight kg 2) 3.2
Sound power level dB(A) 3) 104
Sound pressure level dB(A) 3) 92
Vibration level left/right m/s² 4) 5.8/5.2
Blowing force with BG-KM N 15
Air speed with BG-KM m/s 5) 58
Throughput with BG-KM m³/h 5) 815
Max. air speed with BG-KM m/s 67
Max. throughput with BG-KM m³/h 5) 1.110
Working hours per battery charge with FS-KM, AC and AP 100 min 6) 13/8/6
Working hours per battery charge with FS-KM, AC and AP 200 min 6) 26/15/12
Working hours per battery charge with FS-KM, AC and AP 300 min 6) 38/23/18
Working hours per battery charge with FS-KM, AC and AR 1000 min 6) 100/63/50
Working hours per battery charge with FS-KM, AC and AR 3000 min 6) 190/115/90
Working hours per battery charge with FS-KM, GSB and AP 100 min 6) 24/16/13
Working hours per battery charge with FS-KM, GSB and AP 200 min 6) 50/32/25
Working hours per battery charge with FS-KM, GSB and AP 300 min 6) 75/45/40
Working hours per battery charge with FS-KM, GSB and AR 1000 min 6) 200/130/100
Working hours per battery charge with FS-KM, GSB and AR 3000 min 6) 370/240/190
Working hours per battery charge with FCB-KM and AP 100 min 6) 11/9/6
Working hours per battery charge with FCB-KM and AP 200 min 6) 22/17/11
Working hours per battery charge with FCB-KM and AP 300 min 6) 32/25/17
Working hours per battery charge with FCB-KM and AR 1000 min 6) 90/70/45
Working hours per battery charge with FCB-KM and AR 3000 min 6) 160/130/85
Working hours per battery charge with KW-KM and AP 100 min 6) 15/13/12
Working hours per battery charge with KW-KM and AP 200 min 6) 30/25/23
Working hours per battery charge with KW-KM and AP 300 min 6) 45/40/35
Working hours per battery charge with KW-KM and AR 1000 min 6) 125/110/90
Working hours per battery charge with KW-KM and AR 2000 min 6) 180/155/140
Working hours per battery charge with KW-KM and AR 3000 min 6) 230/190/180
Working hours per battery charge with BF-KM and AP 100 min 6) 15/13/12
Working hours per battery charge with BF-KM and AP 200 min 6) 30/25/23
Working hours per battery charge with BF-KM and AP 300 min 6) 45/40/35
Working hours per battery charge with BF-KM and AR 1000 min 6) 125/110/90
Working hours per battery charge with BF-KM and AR 3000 min 6) 230/190/180
Working hours per battery charge with KB-KM and AP 100 min 6) 15/13/12
Working hours per battery charge with KB-KM and AP 200 min 6) 30/25/23
Working hours per battery charge with KB-KM and AP 300 min 6) 45/40/35
Working hours per battery charge with KB-KM and AR 1000 min 6) 125/110/90
Working hours per battery charge with KB-KM and AR 3000 min 6) 230/190/180
Working hours per battery charge with BG-KM and AP 100 min 6) 13/7/5
Working hours per battery charge with BG-KM and AP 300 min 6) 35/20/13
Working hours per battery charge with BG-KM and AR 1000 min 6) 100/60/40
Working hours per battery charge with BG-KM and AR 3000 min 6) 190/110/70
Working hours per battery charge with HT-KM and AP 100 min 6) 20/15/9
Working hours per battery charge with HT-KM and AP 200 min 6) 40/30/18
Working hours per battery charge with HT-KM and AP 300 min 6) 60/45/30
Working hours per battery charge with HT-KM and AR 1000 min 6) 170/125/75
Working hours per battery charge with HT-KM and AR 3000 min 6) 310/230/140
Working hours per battery charge with FH-KM 145° and AP 100 min 6) 60/50/40
Working hours per battery charge with FH-KM 145° and AP 200 min 6) 120/95/80
Working hours per battery charge with FH-KM 145° and AP 300 min 6) 180/145/120
Working hours per battery charge with FH-KM 145° and AR 1000 min 6) 500/400/330
Working hours per battery charge with FH-KM 145° and AR 3000 min 6) 900/730/600
Working hours per battery charge with HL-KM 135° and AP 100 min 6) 60/50/40
Working hours per battery charge with HL-KM 135° and AP 200 min 6) 120/95/80
Working hours per battery charge with HL-KM 135° and AP 300 min 6) 180/145/120
Working hours per battery charge with HL-KM 135° and AR 1000 min 6) 500/400/330
Working hours per battery charge with HL-KM 135° and AR 3000 min 6) 900/730/600
Working hours per battery charge with SP-KM and AP 100 min 6) 25/21/16
Working hours per battery charge with SP-KM and AP 200 min 6) 50/40/30
Working hours per battery charge with SP-KM and AP 300 min 6) 75/60/50
Working hours per battery charge with SP-KM and AR 1000 min 6) 200/170/130
Working hours per battery charge with SP-KM and AR 2000 min 6) 300/250/200
Working hours per battery charge with SP-KM and AR 3000 min 6) 380/310/240
Working hours per battery charge with FCS-KM and AP 100 min 6) 11/9/6
Working hours per battery charge with FCS-KM and AP 200 min 6) 22/17/11
Working hours per battery charge with FCS-KM and AP 300 min 32/25/17
Working hours per battery charge with FCS-KM and AR 3000 min 6) 90/70/45

1) Basic device to socket
2) Without battery
3) K-factor according to DIR 2006/42/EC = 2.0 dB (A)
4) K-factor according to DIR 2006/42/EC = 2.0 m/s ²
5) In blower mode with round nozzle
6) Level 1/level 2/level 3, the battery working times for each battery charge are estimates and may vary depending on how the tool is used.

Standard Features

  • Quick-release coupling

    The quick-release coupling allows the KombiSystem to be quickly dismantled into two parts for easy transport and storage – and then re-assembled quickly without tools.

  • Control handle with speed control

    The maximum speed can be adjusted to three different levels depending on the task at hand. This saves you energy and extends the battery runtime. The control handle has “Operator Presence Control” with a self-resetting locking lever. This means that it is not possible to start the device up unintentionally.

  • EC-Motor

    The STIHL electric motor (EC) is extremely energy efficient, lightweight and compact. It runs quietly, generates very low vibrations and does not require servicing.

  • Loop Handle

    The loop handled grass trimmers and brushcutters are ideal for working in areas where space is limited, e.g. thinning between bushes and shrubs.

  • Socket

    To transfer power, the socket and the tool is connected to the STIHL AP or AR batteries using the connecting cable. This means that the battery can be conveniently worn on the body.

Accessories

FCB-KM – Bent Shaft Edge Trimmer

This bent-shaft edger attachment is ideal for accurately trimming lawn edges along paths and driveways. The FCB-KM is lightweight & has great manoeuvrability giving users a clean and accurate cut.

RG-KM – Rotary Trimmer

Easily remove weeds and grass from a variety of surfaces including gravel and asphalt areas. This robust and functional, low spin/throw kombi attachment is great when working in noise sensitive, high traffic and dense areas. The low spin/throw action of the cutting head means there is a low risk of damage to nearby objects and is perfect for use along kerbs and roadsides. The attachment is approved for KM 94 RC-E, KM 131 R and KMA 130 R models.

Documents

Download PDF

Versions

  • KMA 130 R Skin Only
